Journal of Organic Chemistry, volume 70, issue 12, pages 4687-4694
Novel Ruthenium-Based Metathesis Catalysts Containing Electron- Withdrawing Ligands: Synthesis, Immobilization, and Reactivity
Tobias S. Halbach
1
,
Stefan Mix
1
,
Dirk Fischer
1
,
Simon Maechling
1
,
Jens O Krause
1
,
Carsten Sievers
1
,
Siegfried Blechert
1
,
Oskar Nuyken
1
,
Michael R. Buchmeiser
1
Publication type: Journal Article
Publication date: 2005-05-05
Journal:
Journal of Organic Chemistry
scimago Q2
SJR: 0.724
CiteScore: 6.2
Impact factor: 3.3
ISSN: 00223263, 15206904
PubMed ID:
15932306
Organic Chemistry
Abstract
The syntheses and reactivity of seven different ruthenium-based metathesis catalysts are described. Ru(CF3COO)2(PCy3)(=CH-2-(2-PrO)C6H4) (1), Ru(CF3COO)2(1,3-dimesityldihydroimidazolin-2-ylidene)(=CH-2-(2-PrO)C6H4) (2), and Ru(CF3COO)2(PCy(3))(1,3-dimesityldihydroimidazolin-2-ylidene)(=CHC6H5) (3) were prepared via chlorine exchange by reacting RuCl2(PCy3)2(=CH-2-(2-PrO)C6H4), RuCl2(1,3-dimesityldihydroimidazolin-2-ylidene)(=CH-2-(2-PrO)C6H4), and RuCl2(PCy3)(1,3-dimesityldihydroimidazolin-2-ylidene)(=CHC6H5), respectively, with silver trifluoroacetate (Cy =cyclohexyl). In analogy, Ru(CF3CF2COO)2(1,3-dimesityldihydroimidazolin-2-ylidene)(=CH-2-(2-PrO)C6H4) (4) and Ru(CF3CF2CF2COO)2(1,3-dimesityldihydroimidazolin-2-ylidene)(=CH-2-(2-PrO)C6H4) (5) were prepared from RuCl2(1,3-dimesityldihydroimidazolin-2-ylidene)(=CH-2-(2-PrO)C6H4) via reaction with CF3CF2COOAg and CF3CF2CF2COOAg, respectively. Ru(C6F5COO)2(1,3-dimesityldihydroimidazolin-2-ylidene)(=CH-2-(2-PrO)C6H4) (6) and Ru(C6F5O)2(1,3-dimesityldihydroimidazolin-2-ylidene)(=CH-2-(2-PrO)C6H4) (7) were prepared from RuCl2(1,3-dimesityldihydroimidazolin-2-ylidene)(=CH-2-(2-PrO)C6H4) via reaction with C6F5COOTl and C6F5OTl, respectively. Supported catalysts Ru(PS-DVB-CH2OOCCF2CF2CF2COO)(CF3COO)(PCy3)(1,3-dimesityldihydroimidazolin-2-ylidene)(=CHC6H5) (8), Ru(PS-DVB-CH2OOCCF2CF2CF2COO)(CF3COO)(PCy3)(=CH-2-(2-PrO)C6H4) (9), and Ru(PS-DVB-CH2OOCCF2CF2CF2COO)(CF3COO)(1,3-dimesityldihydroimidazolin-2-ylidene)(=CH-2-(2-PrO)C6H4) (10) were synthesized by reaction of RuCl2(PCy3)(1,3-dimesityldihydroimidazolin-2-ylidene)(=CHC6H5), RuCl2(PCy3)(=CH-2-(2-PrO)C6H4), and RuCl2(1,3-dimesityldihydroimidazolin-2-ylidene)(=CH-2-(2-PrO)C6H4), respectively, with a perfluoroglutaric acid-derivatized poly(styrene-co-divinylbenzene) (PS-DVB) support (silver form). Halogen exchange in PCy3-containing systems had to be carried out in dichloromethane in order to suppress precipitation of AgCl.PCy3. The reactivity of all new catalysts in ring-closing metathesis (RCM) of hindered electron-rich and -poor substrates, respectively, at elevated temperature (45 degrees C) was compared with that of existing systems. Diethyl diallylmalonate (DEDAM, 11), diethyl allyl(2-methylallyl)malonate (12), N,N-diallyl-p-toluenesulfonamide (13), N-benzyl-N-but-1-en-4-ylbut-2-enecarboxylic amide (14), and N-allyl-N-(1-carboxymethyl)but-3-en-1-yl-p-toluenesulfonamide (15) were used as educts. Supported catalysts were prepared with high loadings (2.4, 22.1, and 160 mg of catalyst/g PS-DVB for 8, 9, and 10, respectively). Catalyst 8 showed higher and catalysts 9 and 10 sowed significantly reduced activities in RCM compared to their homogeneous analogues. Thus, with 8, turnover numbers (TONs) up to 4200 were realized in stirred-batch (carousel) RCM experiments. To elucidate the nature of the bound species, catalysts 8-10 were subjected to 13C- and 31P-MAS NMR spectroscopy. These investigations provided evidence for the proposed structures. Leaching of ruthenium into the reaction mixture was low, resulting in ruthenium contents <85 ppb (ng/g) in the final RCM-derived products.
